Condition: New
Automatic Grade: Automatic
Place of Origin: Jiangsu, China (Mainland)
Brand Name: ZHUOQI
Model Number: RZ1500,RZ2000,RZ2500
Voltage: 380V 50HZ
Power(W): 45~100kw
Dimension(L*W*H):12000*9500*3500mm(L*W*H)
Weight: 1500KG-2500KG
Certification: ISO9001
Warranty: 1 Year
After-sales Service Provided: Engineers available to service machinery overseas
| Packaging Details: | NUDE PACKING FOR SINGLE MACHINE,WOODEN CASE FOR SPARE PARTS |
|---|---|
| Delivery Detail: | 100DAYS |
1. Finished product: thermo-bonded nonwoven fabric
2. Product weight: 18-70 g/m2
3. Working speed: 8-40 m/min
4. Width of the finished product: ≤ 1200mm
5. Raw material: 1.5-2.5D，38-51mm，First grade polyester fiber
6. Heating method: electricity heating up the thermo oil. Heating power: 60kw.
7. Installation power for main machines: 45kw
8. Size of the Machine: Length12000×Width9500×Height3500mm
Name: Opener
Original: China
1.1. Working width: 1000mm
1.2. Capacity: 80-100kg/h
1.3. Installation power: 4.77kw
1.4. Opening cylinder is of card wire roller type
Name: Hopper
Original: China
2.1. Working width: 1200mm
2.2. Capacity: 80-100kg/h
2.3. Installation power: 1.12kw
Name:Pre carding
Original: China
3.1. Working width: 1500mm
3.2. Stripping method: roller stripping
3.3. Carding capacity: 75 kg/h
3.4. Installation power: 6.05kw
Name: Cross lapper
Original: China
4.1. Web in lattice width: 1700mm.( made of artificial leather)
web out lattice width: 1700mm.( made of artificial leather)
4.2. Transmission lattice motor: 1.5 KW, frequency drive
to-and-from lattice motor: 0.75KW, frequency drive
4.1. Web in lattice width: 1700mm.( made of artificial leather)
web out lattice width: 1700mm.( made of artificial leather)
4.2. Transmission lattice motor: 1.5 KW, frequency drive
to-and-from lattice motor: 0.75KW, frequency drive
Name: Edge cutting
Original: China
5.1. Working width: 1500mm
5.2. Stripping method: roller stripping
5.3. Carding capacity: 60kg/h
7.1. Working width: 1500mm.
7.2. Mechanic speed: 10~40m/min.
7.3. Diameter of the roller: Φ370mm length of the roller: 1500mm.
7.4. Heating method: thermo oil circling heating
7.5. Temperature of the roller surface: room temperature~2500C.
Main Features
Name: Winding machine
Original: China
8.1. Working width: 1300mm.
8.2. Maximum roller diameter: 800mm.
8.3. Automatic counting meter: manually tear off the interlining
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
